| Type | Voltage V |
Frequency Hz |
Input Power W |
Current A |
Speed r/min +- 5% | Air Volume m3/h | Noise Level dBA | Capacitor uF/VDE |
|---|---|---|---|---|---|---|---|---|
| CL55235635S | 220v | 50/60Hz | 540/645W | 2.3/2.7A | 1350/1620r/min | - | - | / |
| CL55235635S | 380v | 50/60Hz | 540/645W | 1.4/1.6A | 1350/1620r/min | - | - | / |
M
E
N
U
CL55235635S
Axial Fan Motor 550mm, 220/380v, 50/60Hz 5 Leaf
Model:
550mm
Rated Voltage:
220/380v
Rate Frequency:
50/60Hz
Rated Power:
540/645W
Rated Current:
2.3/2.7A
Rated Speed:
1350/1620r/min
Rotation
SUCTION
Additional Information
