| Type | Voltage V |
Frequency Hz |
Input Power W |
Current A |
Speed r/min +- 5% | Air Volume m3/h | Noise Level dBA | Capacitor uF/VDE |
|---|---|---|---|---|---|---|---|---|
| CL45235635S | 220v | 50/60Hz | 220/260W | 0.95/1.14A | 1380/1650r/min | - | - | / |
| CL45235635S | 380v | 50/60Hz | 220/260W | 0.57/0.68A | 1380/1650r/min | - | - | / |
M
E
N
U
CL45235635S
Axial Fan Motor 450mm, 220v/380v, 50/60Hz 5 Leaf
Model:
450mm
Rated Voltage:
220/380V
Rate Frequency:
50/60Hz
Rated Power:
220/260W
Rated Current:
0.95/1.14A
Rated Speed:
1380/1650r/min
Rotation
SUCTION
