| Type | Voltage V |
Frequency Hz |
Input Power W |
Current A |
Speed r/min +- 5% | Air Volume m3/h | Noise Level dBA | Capacitor uF/VDE |
|---|---|---|---|---|---|---|---|---|
| CL25235635S | 220v | 50/60Hz | 55/65W | 0.23/0.27A | 1400/1650r/min | - | - | / |
| CL25235635S | 380v | 50/60Hz | 55/65W | 0.14/0.16A | 1400/1650r/min | - | - | / |
M
E
N
U
CL25235635S
Axial Fan Motor 250mm, 220v/380v, 50/60Hz 5 Leaf
Model:
250mm
Rated Voltage:
220v/380v
Rate Frequency:
50/60Hz
Rated Power:
55/65W
Rated Current:
0.23/0.27A
Rated Speed:
1400-1650r/min
Rotation
SUCTION
